è un brevetto di proprietà EWOL srl is a patent owned by EWOL srl

The propeller has been designed to be easily installed and removed from the propeller’s shaft, while remaining completely assembled; these operations have infact the advantage of requiring only a few minutes. Please read carefully the following assemblage, disassemblage and maintenance instructions. L’elica è stata progettata per essere facilmente installata e rimossa dall’asse portaelica; queste operazioni hanno infatti il vantaggio di poter essere effettuate in pochi minuti, senza il disassemblaggio dell’elica stessa. Seguire attentamente le istruzioni di montaggio, smontaggio e...

Montaggio sull’asse porta-elica  •  Assemblage on the shaft - Check that the propeller’s shaft cannot rotate by leaving the gear engaged or by blocking it in another way - Insert the complete propeller (hub, body and blades) on the shaft (fig.1 and 2) and keep it in position before fixing - Assicurarsi che l’asse porta-elica non possa ruotare innestando la marcia a motore spento o bloccando l’asse in altra maniera - Innestare il gruppo completo (mozzo, corpo e pale) sull’asse porta-elica (fig.1 e 2) e tenerlo in posizione prima del fissaggio Inserimento elica sull’asse Insertion of...

Installazione della punta   •  Spinner installation - Innestare la punta C e fissarla con le apposite 3 viti inox antisvitamento D (fig.6) - Insert the spinner C and fix it with the appropriate 3 stainless steel self blocking screws D (fig.6) Importante: le viti fornite sono del tipo auto- Important: the screws supplied are of a self blocking type. In case of replacement with other non self blocking screws, a threadlocker medium on the new screws will be needed. frenante; se dovessero essere sostituite con viti non auto-frenanti sarà necessario applicare un prodotto frena-filetti medio...

Regolazione del passo   •  Pitch setting The pitch of a propeller is directly proportional to the blades’ incidence angle. Once your propeller has been installed, the desired pitch can be obtained by using the Micrometric Pitch Setting device (MPS), taking care that the locking screw F has been previously loosened (fig.7). It’s important to know that has been set at an optimal theoretic blade’s angle of 20°, so please verify that mark l located on the MPS ring nut, and the other mark l located on propeller's body, are aligned (fig. 8). The alignment of these two marks corresponds to the...

Come regolare il passo •  How to set the pitch - Allentare la vite di fermo F posta sulla punta (fig.7), ruotandola in senso antiorario; in questo modo la ghiera MPS sarà libera di ruotare (fig.9) - Ruotare la ghiera MPS fino a che l’indicazione dell’angolo desiderato sarà allineata al simbolo l - Serrare la vite di fermo F - Loosen the locking screw F located on the spinner (fig.7) by rotating it anti-clockwise so that the MPS ring nut is free to rotate (fig.9) - Rotate the MPS ring nut until the required angle indication is aligned with mark l - Tighten the locking screw F l Mark...

Once the pitch has been set, the propeller works automatically: the blades take the correct pitch according to the previously set angle in forward and take the fix pitch in reverse. Do not reverse at high RPM in order to avoid damage to the inside components. Una volta regolato il passo, funziona in maniera completamente automatica: le pale prendono il passo rispettando l’angolazione impostata a marcia avanti e si dispongono con passo ad angolazione fissa a marcia indietro. Si raccomanda di evitare inversioni di marcia a regimi del motore elevati per non danneggiare i componenti interni....

Estrazione dell’elica   •  Extraction of the propeller The propeller can be very easily removed from the propeller’s shaft without the use of a hub puller. Proceed as follows: - Remove the spinner C by unscrewing the stainless steel self blocking screws D (fig.12) - Check that the propeller’s shaft cannot rotate by leaving the gear engaged or by blocking it in another way - Loosen the locking bolt B by turning anti-clockwise (fig.13) Lo smontaggio di dall’asse porta-elica può essere effettuato rapidamente senza l’ausilio di estrattori. Procedere come segue: - Rimuovere la punta C allentando...

Protezione catodica   •  Cathodic protection is entirely made of special stainless steels, therefore no cathodic protection with zinc anodes is theoretically needed. However we suggest to install a collar zinc on the propeller’s shaft; this will guarantee better protection mainly for the other components of the boat. We recommend to check periodically the condition of the zinc anode and to replace it if necessary. è interamente realizzata con acciai inossidabili speciali, quindi teoricamente non necessiterebbe di alcuna protezione catodica mediante zinchi; si consiglia tuttavia di...

Innesto del tubo di ingrassaggio Insert of grease gun’s tube Pompaggio del grasso Grease pumping Avvertenze   •  Warnings - Do not service the propeller while the engine is on - Keep far away from the propeller while this is rotating - All maintenance to the propeller while the boat is in the water must be performed in a calm sea to avoid boat pitching which can be dangerous for the operator - Check that the nut and the locking bolt are well tightened before starting the engine - In case the shaft had previously been blocked, remember to unblock it before restarting the engine - Do not...

EWOL s.r.l. - Via Rugabella, 1 - 20122 Milano - Italy Tel. (39) 02 86.46.39.11 - Fax (39) 02 86.91.16.71 info@ewoltech.com www.ewoltech.com
